Key Parameters

Operating Weight

2500KG

Standard bucket capacity

0.1m³

Climbing ability

30°

Maximum Bucket digging force

15.3KN

Maximum Arm digging force

10.5KN

Hydraulic system press

18.0Mpa

Boom length

1000mm

Engine

Emission Standard

Europ 5 /EPA

Brand

Kubota  14.10KW,  20HP, 2000rpm

Optional Engine

Laidong  22.10kw , 2300rpm

Cylinder

3

Size

General size

4170x1300x2280mm

Track distance

1070mm

General Track length

1230mm

Mini ground clearance

230mm

Mini tail swing radius

1180mm

Crawler

Travel Speed

3.5km/h

Track width

230mm

Track number for steel crawler

38pcs

up/Bottom supportin wheel

4

Operating range

Maximum digging height

3700mm

Vertical unloading height

2290mm

Maximum digging depth

2450mm

Maximum digging vertical depth

2160mm

Maximum digging radius

4370mm

Minimum revolution redius

2020mm

Maximum height of  scraper knife

240mm

Maximum depth of scraper knife

310mm

Arm swing angle , Left side

75°

Arm swing angle , Right side

45°
