1.5T Electric Forklift
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Parameters
| Overall length (without forks) | 2200mm |
| Overall length (with forks) | 3170mm |
| Full Width | 1200mm |
| Height without mast lifting | 2100mm |
| Height of overhead guardrail | 1900mm |
| Maximum height during operation | 3750mm |
| Wheelbase | 1580mm |
| Minimum ground clearance at the bottom of the mast | 100mm |
| Minimum ground clearance at the middle of the frame | 130mm |
| Gantry | 120mm C |
| Maximum lifting height without load | 3000mm |
| Free lifting height | 3000mm |
| Mast inclination | 35° |
| Standard machine weight under no-load condition | 2600kg |
| Maximum lifting speed without load (adjustable) | 160mm/s |
| Maximum lifting speed at full load (adjustable) | 190mm/s |
| Minimum turning radius | 1550mm |
| Maximum no-load operating speed (adjustable) | 14km/h |
| Maximum operating speed at full load (adjustable) | 12km/h |
| Maximum climbing grade with full load | 15% |
| Maximum climbing grade without load | 20% |
| Load center distance | 500mm |
| Front wheel specifications | 650-10 |
| Rear wheel specifications | 500-8 |
| Increase motor power | Communication 4.0 |
| Drive motor power | Communication 4.0 |
| Steering Type | Hydraulic power assist |
| Charger input voltage | 220V |
| Charging time | 8-10h |
| Battery capacity | 100ah |
| Rated voltage | 72V |
| Battery Brand | ChaoWei |
| Number of batteries | 6 pieces |
| Drive axle | Cast steel heavy-duty drive axle |
| Transformation Bridge | Cast steel suspended one-piece heavy-duty steering axle |
| Lighting system | LED |
| Four-wheel travel | Solid tires |
| The color of car | Customized options |
| Vehicle license | Qualified |
