Electric forklift - 1.5T-A
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Introduction
| Product Model | 1.5T-A |
| Overall Length | 2200mm without forks |
| 3170mm with forks | |
| Overall Width | 1200mm |
| Overall Height | 2100mm (mast lowered height) |
| 1990mm (top guard height) | |
| 3750mm (maximum working height) | |
| Front Wheel Specification | 650-10 |
| Rear Wheel Specification | 500-8 |
| Lifting Motor | AC 4.0kw |
| Drive Motor | AC 4.0kw |
| Steering Type | Hydraulic Assist |
| Charger Input Voltage | 220v |
| Rated Voltage | 72v |
| Battery Capacity | 100ah |
| Number of Batteries | 6 units |
| Lighting System | LED |
| Wheelbase | 1580mm |
| Minimum Ground Clearance | 100/130mm |
| Gantry Frame | 120mm C |
| Max Lifting Height (without load) | 3000mm |
| Free Lift Height | 3000mm |
| Mast Tilt Angle (Front/Rear) | 35° |
| Unloaded Machine Weight | 2600kg |
| Maximum lifting speed without load | 16mm/s |
| Maximum lifting speed at full load | 19mm/s |
| Minimum Turning Radius | 1550mm |
| Maximum speed without load | 14kw/h |
| Loaded Travel Speed | 12km/h |
| Maximum climbing grade with full load | 15% |
| Maximum climbing grade with out load | 20% |
| Load Center Distance | 500mm |
| Four-Wheel Drive | Solid Tires |
