10m lifting platform
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product Parameters
| Safe working load | 320kg |
| Safe working load of extended platform | 113kg |
| Extended platform dimensions (G) | 0.9m |
| Maximum number of workers | 2 |
| Maximum working height (A) | 12m |
| Maximum platform height (B) | 10m |
| Length of the whole machine (C) | 2600mm |
| Width of the whole machine (D) | 1170mm |
| Height of the whole machine (fence not folded) | 2520mm |
| Height of the whole machine (fence folded) (E) | 1820mm |
| Dimensions of the working platform (length x width (F)) | 2400mm*1170mm |
| Minimum ground clearance (folded state) | 0.1m |
| Minimum ground clearance (lifted state) | 0.019m |
| Wheelbase | 2.0m |
| Minimum turning radius (inner wheel) | 0 |
| Minimum turning radius (outer wheel) | 2.40m |
| Lifting motor/drive motor | 24V/4.0KW |
| Machine travel speed (folded state) | 30m/min |
| Machine travel speed (lifted state) | 10m/min |
| Ascending/descending speed | 80/90 sec |
| Battery | 6V/200Ah*4 |
| Charger | 24V/30A |
| Maximum gradeability | 30% |
| Maximum allowable working angle (X/Y) | 1.5°/3° |
| Tire specifications | Φ381*127 |
| Machine weight | 2400kg |
